Description
Twin-cylinder power and efficiency
The DLE-120 delivers 50 lbs of static thrust—more than enough power for intense 3D maneuvers. Twin opposed cylinders reduce vibration and engine wear and increase performance. It's all packed into a magnesium alloy crankcase that is strong and light.
Mufflers, standoffs and electronic ignition boost performance even further. The DLE-120 delivers the most punch at the lowest weight and the lowest price of any engine in its class. Pick up the DLE-120 and fly with performance-fueled confidence.
Features:
- Efficient, light design for a high power-to-weight ratio
- Light pistons for fast acceleration, excellent compression and low vibration
- CNC-machined parts for high performance and long life
- Sealed crankshaft bearings
- Improved piston and cylinder contact area for increased engine lifespan.
- Matched mufflers included for optimized power
- Two mufflers
- Electronic ignition module with spark plugs
- Standoffs
- Spiral wire wrap
Datasheet
Performance : 13HP / 8500rpm
Idle speed : 1300rpm
Propellor : 27x12 , 28x10 , 28x11 , 29x9
Spark plug : DLE 6
Displacement : 130cm³
Bore x Stroke : 47mm x 37.5mm
Compression ratio : 9.2:1
Ratio of lubricating capacity : 30:1
Net weight : 2500g
Muffler weight : 350g
Ignition weight : 190g
Ignition voltage : 4.8 - 12volt
